58X OIS 6.3~365mm 2MP Network Zoom Camera Module

> Focal length:6.3~365mm, 58× Zoom

> 1/1.8“Sony Progressive Scan CMOS, 4.17 Megapixel

> Supports Optical-Defog,Optical Image Stabilisation,WDR, BLC, HLC, adaptable to multiple application scenarios.

> Clearer:Multiple pieces of aspherical optical glass, excellent transparency-enhancing coating for greatly reduced dispersion and improved resolution.

> Accurate and fast autofocus: with stepper motors drive for multiple applications

> Max. Resolution: 1920×1080@30/25fps

> Min. Illumination: 0.005Lux/F1.5(colour)

> Ease of installation: All-in-one design, plug and play.


  • Module Name: VS-SCZ2058KIO-8
  • Overview

    Product Detail

    Product Tags

    The 58x OIS zoom camera module is a high performance long range optical image stabilization  zoom camera module.

    Powerful 58x zoom ,6.3~365mm,which can provide very long sight distance.

    The built-in optical stabilization  algorithm can greatly reduce the shaking of the image in the case of large zoom, and improve the use experience of applications such as coastal defense and shipborne monitoring.

    OIS

    The OIS lens has an internal motor that physically moves one or more of the glass elements inside the lens as the camera moving. This results in a stabilizing effect, countering the motion of the lens and the camera (from the shaking of the operator’s hands or effect of the wind, for example) and allowing a sharper, less-blurry image to be recorded.

    212  Video

    212  Technical Specification

    Camera
    Sensor Type 1/1.8 " Sony Progressive Scan CMOS
    Effective Pixels 2.16M pixels
    Lens Focal Length 6.3 ~ 365mm
    Zoom 58 ×
    Aperture FNo: 1.5 ~ 6.4
    HFOV (°) 63.4° ~ 1.2°
    VFOV (°) 38.3° ~ 0.6°
    DFOV (°) 70.7° ~ 1.4°
    Close Focus Distance 5m ~ 10m (Wide ~ Tele)
    Zoom Speed 8 Sec (Optics, Wide ~ Tele)
    Video & Audio Network Compression H.265/H.264/H.264H/MJPEG
    Resolution Main Stream: 1920*1080@@50/60fps;

    LVDS:1920*1080@50/60fps

    Video Bit Rate 32kbps ~ 16Mbps
    Audio Compression AAC/MP2L2
    Storage Capabilities TF card, up to 256GB
    Network Protocols ONVIF, HTTP, RTSP, RTP, TCP, UDP
    General Events Motion Detection, Tamper Detection, Scene Changing, Audio Detection, SD Card, Network, Illegal Access
    IVS Tripwire, Intrusion, Loitering, etc.
    Upgrade Support
    Min Illumination Colour: 0.005Lux/F1.5 @ (F1.5, AGC ON)
    Shutter Speed 1/1 ~ 1/30000 Sec
    Noise Reduction 2D / 3D
    Image Settings Saturation, Brightness, Contrast, Sharpness, Gamma, etc.
    Flip Support
    Exposure Model Auto/Manual/Aperture Priority/Shutter Priority/Gain Priority
    Exposure Comp Support
    WDR Support
    BLC Support
    HLC Support
    S/N Ratio ≥ 55dB(AGC Off, Weight ON)
    AGC Support
    White Balance (WB) Auto/Manual/Indoor/Outdoor/ATW/Sodium Lamp/Natural/Street Lamp/One Push
    Day/Night Auto (ICR)/Manual (Colour, B/W)
    Digital Zoom 16×
    Focus Model Auto/Manual/Semi-Auto
    Defog Electronic-Defog / Optical-Defog
    Image Stabilisation Electronical Image Stabilisation (EIS) / Optical Image Stabilisation (OIS)
    External Control 2× TTL3.3V, Compatible with VISCA and PELCO protocols
    Network port Giga Bit Ethernet
    Video Output Network, LVDS
    Baud Rate 9600 (Default)
    Operating Conditions -20℃ ~ +60℃, 20﹪ to 80﹪RH
    Storage Conditions -40℃ ~ +70℃, 20﹪ to 95﹪RH
    Weight 930g
    Power Supply +9 ~ +12V DC (Recommend: 12V)
    Power Consumption Static: 3.5W; Max: 7W
    Dimensions (mm) Length * Width * Height:145*82*96
    Install the positive direction The main board of the camera is facing down
