Uncooled VOx 640*512 Temperature Measurement Network Thermal Camera Module
VS-SCM6 Series· Uncooled VOx 17um 640*512 microbolometer
· NETD is less than 50mk (@25° C, F#=1.0)
· Accurate temperature measurement
· Support ONVIF
Uncooled VOx 640*512 Temperature Measurement Network Thermal Camera Module
VS-SCM6 Series
The network 640*512 Vox temperature measurement thermal camera module use 17um 640*512 microbolometer which is more sensitive and intelligent.
This series is designed for industry-grade infrared temperature measurement.
Features
|
With high resolution and sensitivity, This series modules can monitor equipment conditions and make warnings in a wide range of industrial applications, such as electric power detection, industrial process control, and others. Multiple measurement rules:point,line,polygon area. In this area,the maximum temperature, the lowest temperature and the average temperature can be detected. |
 |
Specifications
|
VS-SCM6 Series
|
|||
|
Sensor
|
Detector
|
Uncooled VOx Microbolometer
|
|
|
Pixel Pitch
|
12μm
|
||
|
Resolution
|
640(H)×512(V)
|
||
|
Spectral Band
|
8~14μm
|
||
|
NETD
|
≤50mK@25℃,F#1.0
|
||
|
Lens
|
Focal Length
|
25mm
|
|
|
F-number
|
F1.0/F1.0/F1.2
|
||
|
Field of view (FOV)
|
24.6*18.5/8.3*6.2/9.2*6.9
|
||
|
Video
& Network |
Video Compression
|
H.265/H.264/MJPEG
|
|
|
Memory Card
|
TF Card，Max.256G
|
||
|
Protocols & APIs
|
Onvif, HTTP, RTSP, RTP, TCP, UDP
|
||
|
Resolution
|
50Hz:25fps@1280×1024
|
||
|
IVS
|
Tripwire/Intrusion/ Loitering
|
||
|
AGC
|
Support
|
||
|
DDE
|
Support
|
||
|
Temperature Measurement |
Point,Line,Polygon area | ||
|
General
|
Power Supply
|
12V DC ±10%
|
|
|
Operating Conditions
|
-20˚C～+60˚C (-4˚F ～ 140˚F) / 20﹪ to 80﹪RH
|
||
|
Storage Conditions
|
-40˚C～+65˚C (-40˚F ～ 149˚F) / 20﹪ to 95﹪RH
|
||
|
Dimension
|
25mm lens：113mm×51mm×61mm |
||
|
Weight
|
25mm lens：230g |
