50X 6~300mm 4MP Network Long Range Zoom Camera Module

VS-SCZ4050NM-8

1/1.8″ 4MP Sensor

6~300mm 50x Zoom for long range surveillance
IP & LVDS dual output

50X 6~300mm 4MP Network Long Range Zoom Camera Module

Overview Specifications Download

GET PRICING/INFO

50X 6~300mm 4MP Network Long Range Zoom Camera Module VS-SCZ4050NM-8

The 4050HM serial zoom modules are equipped with 50× optical zoom lens and 1/1.8″ 4.53 Megapixels Progressive scan CMOS IMX347 sensor. Balanced clarity and low light performance, enhances the overall texture of the image. Fog filter allows the user to islate the NIR wavelength of light for clearer long-range daytime imaging. Universal and abundant hardware interfaces, supports standard serial control commands and network video protocols, making tThe 4050HM serial zoom modules extremely easy to integrate both products and systems.

>50X optical zoom, 6~300mm, 4X digital zoom

>Using SONY 1/1.8 inch 4MP starlight level low illumination sensor, max 4MP(2688×1520) resolution

>Optical defog

>Good support for ONVIF

>Fast and accurate focusing

>Rich interface, convenient for PTZ control

Features

Long Range Coverage

With the telephoto focal length range of 300mm, the camera module is a well fit for middle to long range (over 5KM*) security applications.

Instant Focusing

Focusing speed is crucial in a fast transition (zoom operation) from wide area coverage to detailed close ups, especially for fast moving targets. With in-house Synchronized Instant Focusing algorithm, VISHEEN camera modules are able to achieve smooth and rapid zooming, avoiding missing any key moments.

The camera adopts SONY IMX347 sensor, the latest 4 megapixel starlight level sensor, providing high resolution and excellent illumination.

Compact form factor designed to fit in various camera housing

Specifications

Specification		Description
Sensor	Size	1/1.8" CMOS
Lens	Focal Length	f：6～300mm
	Aperture	FNo：1.4～4.5
	Working Distance	1m～5m（Wide～Tale）
	Angle of View	62° ～ 1.6°
Video Network	Compression	H.265/H.264/H.264H/MJPEG
	Audio Codec	ACC, MPEG2-Layer2
	Audio In Type	Line-In, Mic
	Sampling Frequency	16kHz, 8kHz
	Storage capabilities	TF card, up to 256G
	Network protocol	Onvif,HTTP,RTSP,RTP,TCP,UDP,
	IVS	Tripwire, Intrusion, Loitering Detection, etc.
	General Event	Motion Detection, Tamper Detection, Audio Detection, No SD Card, SD Card Error, Disconnection, IP Conflict, Illegal Access
Resolution		Network output: 50Hz, 25/50fps（2560 x 1440）; 60Hz, 30/60fps（2560 x 1440） LVDS output: 1920*1080@50/60fps
S/N Ratio		≥55dB（AGC Off，Weight ON）
Minimum Illumination		Color：0.004Lux @ (F1.4，AGC ON)
EIS		Electronic Image Stabilization (ON/OFF)
Optical Defog		Support
Exposure Compensation		ON/OFF
HLC		Support
Day/Night		Auto/Manual
Zoom Speed		6.5S（Optics，Wide-Tele）
White Balance		Auto/Manual/ATW/Outdoor/Indoor/Outdoor automatic/ sodium lamp automatic/sodium lamp
Electronic Shutter Speed		Auto Shutter/Manual Shutter（1/3s～1/30000s）
Exposure		Auto/Manual
Noise Reduction		2D; 3D
Image flip		Support
External Control		2*TTL
Focus Mode		Auto/Manual/Semi-Auto
Digital Zoom		4×
Operating Conditions		-30°C～+60°C/20﹪ to 80﹪RH
Storage Conditions		-40°C～+70°C/20﹪ to 95﹪RH
Power Supply		DC 12V±15%（Recommended:12V）
Power Consumption		Static:4.5W; Operating State:5.5W
Dimensions		Length * Width * Height：175.372.277.3
Weight		900g
