30X 4K 8MP 3-Axis Stabilization Drone Gimbal Camera
The 30x payload is a fully-integrated, high performance electro-optical camera payload designed for demanding applications that require clear and precise images.
The control precision is as high as ±0.008 degree which leading the industry. Even when the camera is in the maximum focal length and fast flight, it can still maintain the image stability.
30x optical zoom ,the snap picture resolution can be up to 16MP
It supports recording GPS information when taking photos, which can be used for Pix4D to create maps and 3D models.
Practical and convenient ground control software. It is very easy to operate, support pointing zoom, one key return to middle, mouse or touch screen control.
Support intelligent tracking, etc.
Using network port to control gimbal, abandoning the traditional HDMI way, has good reliability, strong compatibility and powerful function
Video
Specification
| GENERAL | |
| Operating Voltage | 12V~25V DC |
| Power | 8.4W |
| Weight | 842g(Without IDU) |
| Memory Card | Micro SD |
| Dimension(L*W*H) | 96*79*120mm |
| Video Output | Ethernet (RTSP) |
| Interface | Ethernet, Serial (CAN) |
| ENVIRONMENTAL | |
| Work Temperature Range | -10 ~ 60°C |
| Storage Temperature Range | -20 ~ 70°C |
| GIMBAL | |
| Angular Vibration RangeAngular Vibration RangeAngular Vibration RangeAngular Vibration Range | ±0.008° |
| Mount | Detachable |
| Controllable Range | Tilt: +70° ~ -90°; Pan: ±160° |
| Mechanical Range | Tilt: +75° ~ -100°; Pan: ±175°; Roll: +90° ~﹣50° |
| Max Controllable Speed | Tilt: 120º/s; Pan180º/s； |
| Auto-Tracking | Support |
| Cameras | |
| Visible | |
| Sensor | CMOS: 1/1.7″; 12MP |
| Lens | 30× Optical Zoom, F: 6~180mm,FOV(Horizontal): 63~2.5° |
| Photo Formats | JPEG |
| Video Formats | MP4 |
| Operation Modes | Snapshot, Record |
| Defog | E-Defog |
| Exposure Mode | Auto |
| Resolution | (3840×2160)/30fps, 4000×3000(20fps) |
| Noise Reduction | 2D; 3D |
| Electronic Shutter Speed | 1/3~1/30000s |
| OSD | Support |
| TapZoom | Support |
