57X OIS 15~850mm 2MP Network Long Range Zoom Camera Module
Video
Overview
The 57x OIS zoom camera has superior environmental adaptability based on the following functions:
Specification
Optical Image Stabilization (OIS)
The built-in optical image stabilization algorithm can greatly reduce the shaking of the image in the case of large zoom, and improve the use experience of applications such as Coastal Surveillance, Facility Security and Border Security.
Optical Defog
Compared with electronic defog lens, the optical defog lens easier handles extreme scene. For example, when the air is so full of water after rain that it is impossible to see through it to distant objects under normal conditions, even with the electronic defogging mode on. But when optical fogging is switched on can temples and pagodas be seen in the distance (about 7km away from the camera).
Heat Haze Reduction
When the air absorbs heat, the volume becomes larger and the density becomes smaller, resulting in convection (the air floats up). The light passes through the uneven air and undergoes multiple and irregular refraction. Making the image ripple.Heat Haze Reduction, optics optimization of the lens front,double optimization of the back-end algorithm.The camera can ensure good image clarity in a high temperature environment
Compact size
The length is only 32 cm, a 30% reduction in length compared to the same specification bullet camera + C-mount telephoto lens solution, reducing the size of the PTZ housing requirement
| Camera | ||
| Sensor | Type | 1/1.8" Sony Progressive Scan CMOS |
| Lens | Focal Length | 15 ～ 850mm |
| Zoom | 57× | |
| Aperture | FNo: 2.8 ～ 6.5 | |
| HFOV | 29.1° ～ 0.5° | |
| VFOV | 16.7° ～ 0.2° | |
| DFOV | 33.2° ～ 0.6° | |
| Close Focus Distance | 1m ～ 10m (Wide ～ Tele) | |
| Zoom Speed | 8 Sec (Optics, Wide ～ Tele) | |
| Video & Audio Network | Compression | H.265/H.264/H.264H/MJPEG |
| Resolution | Main Stream:1080P@25/30fps;720P@25/30fps Sub Stream 1:D1@25/30fps; CIF@25/30fps Sub Stream 2:1080P@25/30fps; 720P@25/30fps;D1@25/30fps LVDS:1080P@25/30fps | |
| Video Bit Rate | 32kbps ～ 16Mbps | |
| Audio Compression | AAC/MP2L2 | |
| Storage Capabilities | TF card, up to 256GB | |
| Network Protocols | ONVIF, HTTP, RTSP, RTP, TCP, UDP | |
| General Events | Motion Detection, Tamper Detection, Scene Changing, Audio Detection, SD Card, Network, Illegal Access | |
| IVS | Tripwire, Intrusion, Loitering, etc. | |
| Upgrade | Support | |
| Min Illumination | Colour: 0.05Lux@ (F2.8, AGC ON) | |
| Shutter Speed | 1/1 ～ 1/30000 Sec | |
| Noise Reduction | 2D / 3D | |
| Image Settings | Saturation, Brightness, Contrast, Sharpness, Gamma, etc. | |
| Flip | Support | |
| Exposure Model | Auto/Manual/Aperture Priority/Shutter Priority/Gain Priority | |
| Exposure Comp | Support | |
| WDR | Support | |
| BLC | Support | |
| HLC | Support | |
| S/N Ratio | ≥ 55dB (AGC Off, Weight ON) | |
| AGC | Support | |
| White Balance (WB) | Auto/Manual/Indoor/Outdoor/ATW/Sodium Lamp/Natural/Street Lamp/One Push | |
| Day/Night | Auto (ICR)/Manual (Colour, B/W) | |
| Digital Zoom | 16× | |
| Focus Model | Auto/Manual/Semi-Auto | |
| Defog | Electronic-Defog / Optical-Defog | |
| Image Stabilisation | Electronical Image Stabilisation (EIS)Optical Image Stabilisation (OIS) | |
| Heat Haze Reduction | Support | |
| External Control | 2× TTL3.3V, Compatible with VISCA and PELCO protocols | |
| Video Output | Network & LVDS | |
| Baud Rate | 9600 (Default) | |
| Operating Conditions | -30℃ ～ +60℃; 20﹪ to 80﹪RH | |
| Storage Conditions | -40℃ ～ +70℃; 20﹪ to 95﹪RH | |
| Weight | 3255g | |
| Power Supply | +9 ～ +12V DC (Recommend: 12V) | |
| Power Consumption | Static: 4W; Max: 9.5W | |
| Dimensions (mm) | Length * Width * Height：320*109*109 | |
