35X 6~210mm 2MP Starlight Network Zoom Block Camera Module
VS-SCZ2035NM-81/2″ 2MP Sensor
6~210mm 35x Zoom for mid range surveillance
IP & LVDS dual output
>35X optical zoom, 6~210mm, 4X digital zoom
>Using SONY 1/2 inch starlight level low illumination sensor, good imaging effect
>Optical defog
>Abundant interface, two TTL serial port, convenient for PTZ control
>Good support for ONVIF
>Fast and accurate focusing
>Network, LVDS, SDI Output
| View Sheen VS--SCZ2035 Intelligent Network Zoom Camera Module (Camera Block), the Core Components of CCTV PTZ camera and UAV/Drone GIMBAL Pods Designed for Heavy Duty/Payload and Professional Pan/tilt units and Professional UAV/Drone 2MP Full HD Resolution and 35X Optical Zoom |
|
The 35x starlight zoom camera module is a cost-effective 1/2 inch block camera which equipped with 35x optical zoom lens which provides the power to see objects which is long distance away . 35x optical zoom ,optical defog, stronger environmental adaptability. It can be used for long-distance inspection or some environment with mist such as seaside. |
 |
 |
The camera adopts imx385 sensor, IMX385 realizes high sensitivity approximately twice that of the IMX185.It can pursues picture quality at low illuminance most needed by cameras for industrial applications. |
| Sensor | Type | 1 / 2" Sony Progressive Scan CMOS | |
| Effective Pixels | 2.13 M Pixels | ||
| Lens | Focal Length | 6 ～ 210mm | |
| Optical Zoom | 35× | ||
| Aperture | FNo: 1.5 ～ 4.8 | ||
| HFOV (°) | 49.7° ～ 1.5° | ||
| VFOV (°) | 29.2° ～ 0.8° | ||
| DFOV (°) | 56.0° ～ 1.7° | ||
| Close Focus Distance | 1m ～ 1.5m (Wide ～ Tele) | ||
| Zoom Speed | 4.5 Sec (Optics, Wide ～ Tele) | ||
| Video & Audio Network | Compression | H.265/H.264/H.264H/MJPEG | |
| Resolution | Main Stream: 1080P@25/30fps; 1280*960@25/30fps; 720P@25/30fps
Sub Stream1: D1@25/30fps; CIF@25/30fps Sub Stream2: 1080P@25/30fps; 720P@25/30fps; D1@25/30fps |
||
| Video Bit Rate | 32kbps ～ 16Mbps | ||
| Audio Compression | AAC / MP2L2 | ||
| Storage Capabilities | TF card, up to 256GB | ||
| Network Protocols | ONVIF, HTTP, RTSP, RTP, TCP, UDP | ||
| General Events | Motion Detection, Tamper Detection, Scene Changing, Audio Detection, SD Card, Network, Illegal Access | ||
| IVS | Tripwire, Intrusion, Loitering, etc. | ||
| Upgrade | Support | ||
| Min Illumination | Colour: 0.001Lux/F1.5; B/W: 0.0001Lux/F1.5 | ||
| Shutter Speed | 1 / 3 ～ 1 / 30000 Sec | ||
| Noise Reduction | 2D / 3D | ||
| Image Settings | Saturation, Brightness, Contrast, Sharpness, Gamma, etc. | ||
| Flip | Support | ||
| Exposure Model | Auto/Manual/Aperture Priority/Shutter Priority/Gain Priority | ||
| Exposure Comp | Support | ||
| WDR | Support | ||
| BLC | Support | ||
| HLC | Support | ||
| S/N Ratio | ≥ 55dB（AGC Off, Weight ON） | ||
| AGC | Support | ||
| White Balance (WB) | Auto/Manual/Indoor/Outdoor/ATW/Sodium Lamp/Natural/Street Lamp/One Push | ||
| Day/Night | Auto (ICR)/Manual (Colour, B/W) | ||
| Digital Zoom | 16× | ||
| Focus Model | Auto/Manual/Semi-Auto | ||
| Defog | Electronic-Defog (Default); Optical-Defog (Option) | ||
| Image Stabilisation | Electronical Image Stabilisation (EIS) | ||
| External Control | 2× TTL3.3V, Compatible with VISCA and PELCO protocols | ||
| Video Output | Network & LVDS | ||
| Baud Rate | 9600 (Default) | ||
| Operating Conditions | -30℃ ～ +60℃; 20﹪ to 80﹪RH | ||
| Storage Conditions | -40℃ ～ +70℃; 20﹪ to 95﹪RH | ||
| Weight | 410g | ||
| Power Supply | +9 ～ +12V DC (Recommend: 12V) | ||
| Power Consumption | Static: 4.0W; Max: 5.5W | ||
| Dimensions (mm) | Length * Width * Height：126.2*54*67.8 | ||
| Install the positive direction | The main board of the camera is facing down | ||
