50X 6~300mm 2MP Starlight Network Zoom Block Camera Module
The 50x starlight zoom camera module is a high performance long range zoom block camera.
50x optical zoom ,optical defog, stronger environmental adaptability. It can be used for long-distance inspection or some environment with mist such as seaside.
The camera adopts imx385 sensor, IMX385 realizes high sensitivity approximately twice that of the IMX185.It can pursues picture quality at low illuminance most needed by cameras for industrial applications.
50x optical zoom ,optical defog, stronger environmental adaptability. It can be used for long-distance inspection or some environment with mist such as seaside.
The camera adopts imx385 sensor, IMX385 realizes high sensitivity approximately twice that of the IMX185.It can pursues picture quality at low illuminance most needed by cameras for industrial applications.
Compared with the 1/2.8 inch 300mm camera, the picture of this 1/2 inch 300mm block camera is more delicate, and the low illumination is better.
Technical Specification
|
Specification |
Description |
|
|
Sensor |
Image Sensor |
1/2" Sony CMOS |
|
Lens |
Focal Length |
6mm~300mm, 50× Zoom |
|
Aperture |
F1.4~F4.5 |
|
|
Close Focus Distance |
0.1m~1.5m (Wide～Tale) |
|
|
Field of View |
60°~1.8° |
|
|
Video & Network |
Compression |
H.265/H.264/H.264H/MJPEG |
|
Audio Codec |
ACC, MPEG2-Layer2 |
|
|
Audio In Type |
Line-In, Mic |
|
|
Sampling Frequency |
16kHz, 8kHz |
|
|
Storage Capabilities |
TF card, up to 256G |
|
|
Network Protocols |
Onvif, GB28181, HTTP, RTSP, RTP, TCP, UDP |
|
|
IVS |
Tripwire, Intrusion, Loitering Detection, etc. |
|
|
General Event |
Motion Detection, Tamper Detection, Audio Detection, No SD Card, SD Card Error, Disconnection, IP Conflict, Illegal Access |
|
|
Resolution |
50Hz: 25fps@2Mp(1920×1080); 60Hz: 30fps@2Mp(1920×1080) |
|
|
S/N Ratio |
≥55dB (AGC Off, Weight ON) |
|
|
Minimum Illumination |
Color: 0.001Lux/F1.6; B/W: 0.0001Lux/F1.6 |
|
|
EIS |
ON/OFF |
|
|
Defog |
ON/OFF |
|
|
Exposure Compensation |
ON/OFF |
|
|
HLC |
ON/OFF |
|
|
Day/Night |
Auto(ICR)/Manual(Color,B/W) |
|
|
Zoom Speed |
6.5S（Wide-Tele） |
|
|
White Balance |
Auto/Manual/ATW/Outdoor/Indoor/Outdoor automatic/ sodium lamp automatic/sodium lamp |
|
|
Electronic Shutter Speed |
Auto Shutter(1/3s～1/30000s) , Manual Shutter(1/3s～1/30000s) |
|
|
Exposure |
Auto/Manual |
|
|
Noise Reduction |
2D; 3D |
|
|
Flip |
Support |
|
|
Control Interface |
2×TTL |
|
|
Focus Model |
Auto／Manual／Semi-Auto |
|
|
Digital Zoom |
4× |
|
Operating Conditions |
-30°C~+60°C/20% to 80%RH |
|
Storage Conditions |
-40°C~+70°C/20% to 95%RH |
|
Power Supply |
DC 12V±15% (Recommend: 12V) |
|
Power Consumption |
Static Power: 4.5W; Operating Power: 5.5W |
|
Dimensions(L*W*H) |
Approx. 175.3mm*72.2mm*77.3mm |
|
Weight |
Approx. 900g |
Dimensions
